Get a single entry

You can use the GET operation to get an entry from the form. The following table lists details about this GET operation.

URL qualifier

/entry/{formName}/{entryId}

formName - The form for which an entry is to be read.
entryId - The entry ID.

MethodGET
Headers
HeaderValue
Authorizationtoken
(Optional) X-AR-Client-TypeClient Type ID
(Optional) X-AR-RPC-QueueRPC queue to which the client calls are routed
(Optional) X-AR-Timeout

Timeout (in seconds) for REST request

Default value —120 seconds

(Optional) X-AR-TR-Core-IdThe core ID in a trace ID
(Optional) X-AR-TR-CounterThe counter in a trace ID
(Optional) X-AR-Trace-IdThe complete trace ID
(Optional) X-AR-TR-Is-Counter-LockedThe lock counter
Parameters

Name

Description

fieldsSelects what parts of the JSON document to return
For example,
fields=values(field name1, field name2).
expandExpands the related entries (associations).

For more information, see Endpoints in AR REST API.

ReturnsAn entry object
All possible error codes

If the request is not successful, one of the following error codes is returned:

  • 400 - Request body is incorrect
  • 403 - Forbidden
  • 404 - Form does not exist
  • 500 - Internal Server Error

For more information, see Error handling for the REST API.

NotesThe entry object will contain field values for all data fields to which the user has permission.

Request URL

GET

Request header

Authorization: AR-JWT eyJhbGciOiJIUzI1NiJ9. eyJleHAiOjE0MTc2NTM1ODgsInN1YiI6IkFsbGVuIiwibmJmIjoxNDE3NjQ5ODY4LCJpc3MiOi JXLUNTRUlFUk9FLTI5LmFkcHJvZC5ibWMuY29tIiwianRpI joiSURHQUFCRFVDMllHSUFONkJGUTJBQUFFUEZBNVFXIiwiX2NhY2hlSWQiOjQ3LCJpYXQiOjE0MTc2NDk5ODh9. V4LGLcEdwD8V_I4rzoWYYSZmEMA82LBB_lEfz4Xnz9Y

Following is a sample code snippet for the GET operation.

package com.example; import java.nio.charset.StandardCharsets; import org.apache.http.HttpEntity; import org.apache.http.client.methods.CloseableHttpResponse; import org.apache.http.client.methods.HttpGet; import org.apache.http.impl.client.CloseableHttpClient; import org.apache.http.impl.client.HttpClients; import org.apache.http.util.EntityUtils; public class Get { public static void main(String[] args) throws Exception { String token = args[0]; // start HTTP GET to get an entry CloseableHttpClient httpClient = HttpClients.createDefault(); HttpGet httpGet = new HttpGet( ""); // add the token to the header httpGet.addHeader("Authorization", "AR-JWT " + token); // make the call and print the status try (CloseableHttpResponse response = httpClient.execute(httpGet)) { HttpEntity entity = response.getEntity(); String jsonEntry = EntityUtils.toString(entity, StandardCharsets.UTF_8); System.out.println(jsonEntry); } } }

Response Body

HTTP/1.1 200 OK Date: Wed, 03 Dec 2014 22:53:46 GMT Content-Type: application/json Server: Jetty(8.1.15.v20140411) { "values":{ "Request ID":"000000000000103", "Submitter":"Allen", "Create Date":"2014-12-03T22:53:37.000+0000", "Assigned To":null, "Last Modified By":"chris", "Modified Date":"2014-12-03T22:53:37.000+0000", "Status":"New", "Short Description":"testing 123", "Status History":{ "New":{ "user":"chris", "timestamp":"2014-12-03T22:53:37.000+0000" } } }, "_links":{ "self":[ { "href":"" } ] } }

Update an entry

You can use the PUT operation to modify an entry on a form. The following table lists details about the PUT operation for updating a single entry on a form.

URL qualifier

/entry/{formName}/{entryId}

formName - The form for which an entry is to be updated.
entryId - The entry ID.

MethodPUT
Headers
HeaderValue
Authorizationtoken
Content-Typeapplication/json
(Optional) If-Unmodified-SinceHTTP Date
(Optional) X-AR-Client-TypeClient Type ID
(Optional) X-AR-RPC-QueueRPC queue to which the client calls are routed
(Optional) X-AR-Timeout

Timeout (in seconds) for REST request

Default value —120 seconds

(Optional) X-AR-TR-Core-IdThe core ID in a trace ID
(Optional) X-AR-TR-CounterThe counter in a trace ID
(Optional) X-AR-Trace-IdThe complete trace ID
(Optional) X-AR-TR-Is-Counter-LockedThe lock counter
Request BodyAn entry object in a JSON format
Returns

HTTP status code 204 indicates a successful update.

If the client sends If-Unmodified-Since and the entry is modified since that time, then the entry is not updated and status code 412 is returned.

Errors

If the request is not successful, one of the following error codes are returned:

  • 400 - Request body is incorrect
  • 403 - Forbidden
  • 404 - Form does not exist
  • 500 - Internal Server Error

For more information, see Error handling for the REST API.

The following example returns an updated entry in a Simple form.

Request URL

PUT

Request headers

Authorization: AR-JWT eyJhbGciOiJIUzI1NiJ9. eyJleHAiOjE0MTc2NTM1ODgsInN1YiI6IkFsbGVuIiwibmJmIjoxNDE3NjQ5ODY4LCJpc3MiOi JXLUNTRUlFUk9FLTI5LmFkcHJvZC5ibWMuY29tIiwianRpI joiSURHQUFCRFVDMllHSUFONkJGUTJBQUFFUEZBNVFXIiwiX2NhY2hlSWQiOjQ3LCJpYXQiOjE0MTc2NDk5ODh9. V4LGLcEdwD8V_I4rzoWYYSZmEMA82LBB_lEfz4Xnz9Y Content-Length: 59 Content-Type: application/json

Request Body

{ "values":{ "Submitter":"Allen", "Short Description":"testing 123" } }

The following is a sample code snippet for the PUT operation.

package com.example; import org.apache.http.StatusLine; import org.apache.http.client.methods.CloseableHttpResponse; import org.apache.http.client.methods.HttpPut; import org.apache.http.entity.ContentType; import org.apache.http.entity.StringEntity; import org.apache.http.impl.client.CloseableHttpClient; import org.apache.http.impl.client.HttpClients; public class Put { public static void main(String[] args) throws Exception { String token = args[0]; // start HTTP PUT to modify an entry CloseableHttpClient httpClient = HttpClients.createDefault(); HttpPut httpPut = new HttpPut( ""); // build the JSON entry String json = "{ \"values\" : { "; json += "\"Short Description\" : \"updated via REST\""; json += " } }"; httpPut.setEntity(new StringEntity(json, ContentType.APPLICATION_JSON)); httpPut.addHeader("Authorization", "AR-JWT " + token); // make the call and print the status try (CloseableHttpResponse response = httpClient.execute(httpPut)) { StatusLine status = response.getStatusLine(); System.out.println(status); } } }

Update an entry with attachments

The PUT operation also enables you to modify an attachment for a particular entry or from a list of entries.

URL qualifier

/entry/{formName}/{entryId}

formName - The form for which an entry is to be updated.
entryId - The entry ID.

MethodPUT
Headers
HeaderValue
Authorizationtoken
Content-Typemultipart/form-data
(Optional) If-Unmodified-SinceHTTP Date
(Optional) X-AR-Client-TypeClient Type ID
(Optional) X-AR-RPC-QueueRPC queue to which the client calls are routed
(Optional) X-AR-Timeout

Timeout (in seconds) for REST request

Default value —120 seconds

(Optional) X-AR-TR-Core-IdThe core ID in a trace ID
(Optional) X-AR-TR-CounterThe counter in a trace ID
(Optional) X-AR-Trace-IdThe complete trace ID
(Optional) X-AR-TR-Is-Counter-LockedThe lock counter
Request Body

A multipart/form-data entity. Each part of a multipart entity has a name, a Content-Type and the value.

There is one part named as entry with Content-Type as application/json and the value is a JSON entry. There are 0 or more parts with names like attach-{fieldName} with any Content-Type and any value. The name is a prefix indicating that it is an attachment binary data, the part after the hyphen is the name of the attachment field. This updates an entry with attachment data.

Returns

HTTP status code 204 indicates a successful update.

If the client sends If-Unmodified-Since and the entry is modified since that time, then the entry is not updated and status code 412 is returned.

Errors

If the request is not successful, one of the following error codes are returned:

  • 400 - Request body is incorrect
  • 403 - Forbidden
  • 404 - Form does not exist
  • 500 - Internal Server Error

For more information, see Error handling for the REST API.

Delete an entry

The DELETE operation enables you to delete an entry from a form. The following table lists details about this DELETE operation.

URL qualifier

/entry/{formName}/{entryId}

formName - The form for which entry is to be deleted.
entryId - The entry ID.

MethodDELETE
Headers
HeaderValue
Authorizationtoken
(Optional) X-AR-Client-Type Client Type ID
(Optional) X-AR-RPC-QueueRPC queue to which the client calls are routed
(Optional) X-AR-Timeout

Timeout (in seconds) for REST request

Default value—120 seconds

(Optional) X-AR-TR-Core-IdThe core ID in a trace ID
(Optional) X-AR-TR-CounterThe counter in a trace ID
(Optional) X-AR-Trace-IdThe complete trace ID
(Optional) X-AR-TR-Is-Counter-LockedThe lock counter
ReturnsNo request body, but HTTP status 204 indicates successful deletion.
All possible error codes

If the request is not successful, one of the following error codes are returned:

  • 403 - Forbidden
  • 404 - Form does not exist
  • 500 - Internal Server Error

For more information, see Error handling for the REST API.

NotesYou can also use the option FORCE to force delete all the list of entries, for example, ?options=FORCE.

The following example allows you to delete an entry from the form.

Request URL

DELETE

Request header

Authorization: AR-JWT eyJhbGciOiJIUzI1NiJ9. eyJleHAiOjE0MTc2NTM1ODgsInN1YiI6IkFsbGVuIiwibmJmIjoxNDE3NjQ5ODY4LCJpc3MiOi JXLUNTRUlFUk9FLTI5LmFkcHJvZC5ibWMuY29tIiwianRpI joiSURHQUFCRFVDMllHSUFONkJGUTJBQUFFUEZBNVFXIiwiX2NhY2hlSWQiOjQ3LCJpYXQiOjE0MTc2NDk5ODh9. V4LGLcEdwD8V_I4rzoWYYSZmEMA82LBB_lEfz4Xnz9Y

Following is a sample code snippet for the DELETE operation.

package com.example; import org.apache.http.StatusLine; import org.apache.http.client.methods.CloseableHttpResponse; import org.apache.http.client.methods.HttpDelete; import org.apache.http.impl.client.CloseableHttpClient; import org.apache.http.impl.client.HttpClients; public class Delete { public static void main(String[] args) throws Exception { String token = args[0]; // start HTTP DELETE to delete an entry CloseableHttpClient httpClient = HttpClients.createDefault(); HttpDelete httpDelete = new HttpDelete( ""); // add the token to the header httpDelete.addHeader("Authorization", "AR-JWT " + token); // make the call and print the status try (CloseableHttpResponse response = httpClient.execute(httpDelete)) { StatusLine status = response.getStatusLine(); System.out.println(status); } } }

Response Body

HTTP/1.1 204 No Content Date: Wed, 03 Dec 2014 22:38:14 GMT Server: Jetty(8.1.15.v20140411)
